6 To Make Measurements RIGOL
DS6000 User’s Guide 6-33
4. Adjust the X (Y) cursor positions (note that under the same menu
page, you can also press
continuously to switch the current
cursor)
When the display mode is "X" or when the display mode is "X-Y" and
SelectCursor is set to "X", you can adjust the positions of the X cursors.
Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursors A and B at the same time: press CursorAB and use to
adjust the positions of cursors A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable ranges are limited within the screen.
When the display mode is "Y" or when the display mode is "X-Y" and
SelectCursor is set to "Y", you can adjust the positions of the Y cursors.
Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
Adjust cursors A and B at the same time: press CursorAB and use to
adjust the positions of cursors A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable ranges are limited within the screen.
