12 Store and Recall RIGOL
DS6000 User’s Guide 12-19
Track
AXIS Y
Cursor A CH1
Cursor B CH1
Horizontal Positions of the X Cursors
CursorA -4*1 μs
CursorB 4*1 μs
Storage Setting (SAVE)
Storage Type Picture
Picture Storage
Picture Type png
Parameter Save OFF
Inverted OFF
Color Color
Header OFF
Footer OFF
CSV Storage
Data Depth Displayed
Parameter Save OFF
Sequence ON
Utility Function Setting (UTIL)
I/O Setting
Network
Configuration Mode
DHCP, Auto IP
USB Device Computer
Sound
Sound OFF
Pass/Fail Test
Enable Test OFF
Source CH1
Operate OFF
X Mask 0.24div
Y Mask 0.38div
Message Display OFF
Stop On Output OFF
Output Fail
