4 To Set the Sample System RIGOL

DS6000 User’s Guide 4-3

number of averages. The number of averages can be set to 2, 4, 8, 16, 32, 64, 128,

256, 512, 1024, 2048, 4096 or 8192 and the default is 2.

The Waveform before Average:

The Waveform after 256 Averages:
