1
2
7
4
8
9
10
11
12
13
14
15
6
3
5
Figure 4.2 Front Panel (2-channel Model)
1
10.1'' Capacitive Touch Screen 9 Trigger Controls
2 Multipurpose Knobs 10 Vertical Controls
3 Measure Key 11 Horizontal Controls
4
Cursor Key 12 Probe Compensation Signal
Output Terminal/Ground Terminal
5 Analyse Key 13 Analog Channel Input Terminals
6 Touch Lock Key 14 USB HOST Port
7 Common Tools Keys 15 Power Switch
8
Quick Action Key (Self-defined
function)
Product Overview
10
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
