Product Overview
HDO1000 series digital oscilloscope is designed to meet the requirements for the
design, debug, and test of the mainstream oscilloscope market. Adopting the brand-
new chipset "Centaurus" developed by RIGOL, this series achieves a fast waveform
capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 100 Mpts memory
depth, 12-bit resolution, all combined with excellent noise floor performance and
vertical accuracy to meet your requirements for more accurate measurements.
4.1 Front Panel Overview
1
2
7
4
8
9
10
11
12
13
14
15
6
3
5
Figure 4.1 Front Panel (4-channel Model)
