Rigol MSO1104Z Programming Guide

RIGOL Chapter 2 Command System
2-116 MSO1000Z/DS1000Z Programming Guide
:MEASure:SOURce
Syntax
:MEASure:SOURce <sour>
:MEASure:SOURce?
Description
Set or query the source of the current measurement parameter.
Parameter
Name
Type
Range
Default
<sour>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH}
CHANnel1
Explanation
 Analog channels CH1 to CH4 can be selected no matter wether they are currently
turned on. Note: When any of channels D0 to D7 is turned on, CH4 cannot be
selected; when any of channels D8 to D15 is selected, CH3 cannnot be selected.
 For digital channels D0 to D15, only channels currently turned on can be selected.
 This command is used to set the source for the measurement parameters (except
delay and phase). The delay and phase measurements requires two sources which
can be set by the :MEASure:SETup:DSA
and :MEASure:SETup:DSB, :MEASure:SETup:PSA and :MEASure:SETup:PSB
commands respectively.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or MATH.
Example
:MEASure:SOURce CHANnel2 /*Set the parameter measurement source to CH2*/
:MEASure:SOURce? /*The query returns CHAN2*/
Related
Command
:MEASure:ITEM
:MEASure:COUNter:SOURce
Syntax
:MEASure:COUNter:SOURce <sour>
:MEASure:COUNter:SOURce?
Description
Set or query the source of the frequency counter, or disable the frequency counter.
Parameter
Name
Type
Range
Default
<sour>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
OFF
Explanation
 Analog channels CH1 to CH4 can be selected no matter wether they are currently
turned on. Note: When any of channels D0 to D7 is turned on, CH4 cannot be
selected; when any of channels D8 to D15 is selected, CH3 cannnot be selected.
 For digital channels D0 to D15, only channels currently turned on can be selected.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:MEASure:COUNter:SOURce CHANnel2 /*Set the source of the frequency counter to
CH2*/
:MEASure:COUNter:SOURce? /*The query returns CHAN2*/
Related
Command
:MEASure:COUNter:VALue?
