RIGOL Chapter 2 Command System
2-56 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:PARallel
The :DECoder<n>:PARallel commands are used to set the parallel decoding parameters.
Command List:
 :DECoder<n>:PARallel:CLK
 :DECoder<n>:PARallel:EDGE
 :DECoder<n>:PARallel:WIDTh
 :DECoder<n>:PARallel:BITX
 :DECoder<n>:PARallel:SOURce
 :DECoder<n>:PARallel:POLarity
 :DECoder<n>:PARallel:NREJect
 :DECoder<n>:PARallel:NRTime
 :DECoder<n>:PARallel:CCOMpensation
 :DECoder<n>:PARallel:PLOT
:DECoder<n>:PARallel:CLK
Syntax
:DECoder<n>:PARallel:CLK <clk>
:DECoder<n>:PARallel:CLK?
Description
Set or query the CLK channel source of parallel decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<clk>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:DECoder1:PARallel:CLK D0 /*Set the CLK channel source of parallel decoding to
D0*/
:DECoder1:PARallel:CLK? /*The query returns D0*/
