RIGOL Chapter 2 Command System
2-48 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:IIC
The :DECoder<n>:IIC commands are used to set the I2C decoding parameters.
Command List:
 :DECoder<n>:IIC:CLK
 :DECoder<n>:IIC:DATA
 :DECoder<n>:IIC:ADDRess
:DECoder<n>:IIC:CLK
Syntax
:DECoder<n>:IIC:CLK <clk>
:DECoder<n>:IIC:CLK?
Description
Set or query the signal source of the clock channel in I2C decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<clk>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:DECoder1:IIC:CLK D0 /*Set the signal source of the clock channel in I2C decoding
to D0*/
:DECoder1:IIC:CLK? /*The query returns D0*/
:DECoder<n>:IIC:DATA
Syntax
:DECoder<n>:IIC:DATA <dat>
:DECoder<n>:IIC:DATA?
Description
Set or query the signal source of the data channel in I2C decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<dat>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:DECoder1:IIC:DATA D1 /*Set the signal source of the data channel in I2C decoding
to D1*/
:DECoder1:IIC:DATA? /*The query returns D1*/
