Rigol MSO1104Z Programming Guide

RIGOL Chapter 2 Command System
2-16 MSO1000Z/DS1000Z Programming Guide
:CURSor Commands
The :CURSor commands are used to measure the X-axis value (such as time) and Y-axis value (such as
voltage) of the waveform displayed on the screen.
Command List:
 :CURSor:MODE
 :CURSor:MANual
 :CURSor:TRACk
 :CURSor:AUTO
 :CURSor:XY
:CURSor:MODE
Syntax
:CURSor:MODE <mode>
:CURSor:MODE?
Description
Set or query the cursor measurement mode.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{OFF|MANual|TRACk|AUTO|XY}
OFF
Explanation
 OFF: disable the cursor measurement function.
 MANual: enable the manual cursor measurement mode.
 TRACk: enable the track cursor measurement mode.
 AUTO: enable the auto cursor measurement mode.
 XY: enable the XY cursor measurement mode. This mode is valid only when the
horizontal timebase mode is XY.
Return
Format
The query returns OFF, MAN, TRAC, AUTO, or XY.
Example
:CURSor:MODE MANual /*Enable the manual cursor measurement mode*/
:CURSor:MODE? /*The query returns MAN*/
Related
Commands
:CURSor:MANual
:CURSor:TRACk
:CURSor:XY
:TIMebase:MODE
