Rigol MSO1104Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-71
:FUNCtion Commands
The :FUNCtion commands are used to set the waveform recording and playback parameters.
Command List:
 :FUNCtion:WRECord:FEND
 :FUNCtion:WRECord:FMAX?
 :FUNCtion:WRECord:FINTerval
 :FUNCtion:WRECord:PROMpt
 :FUNCtion:WRECord:OPERate
 :FUNCtion:WRECord:ENABle
 :FUNCtion:WREPlay:FSTart
 :FUNCtion:WREPlay:FEND
 :FUNCtion:WREPlay:FMAX?
 :FUNCtion:WREPlay:FINTerval
 :FUNCtion:WREPlay:MODE
 :FUNCtion:WREPlay:DIRection
 :FUNCtion:WREPlay:OPERate
 :FUNCtion:WREPlay:FCURrent
:FUNCtion:WRECord:FEND
Syntax
:FUNCtion:WRECord:FEND <frame>
:FUNCtion:WRECord:FEND?
Description
Set or query the end frame of waveform recording.
Parameter
Name
Type
Range
Default
<frame>
Integer
1 to the maximum number of frames can be
recorded currently
5000
Explanation
Use the :FUNCtion:WRECord:FMAX? command to query the maximum number of frames
can be recorded currently.
Return
Format
The query returns the current end frame in integer.
Example
:FUNCtion:WRECord:FEND 4096 /*Set the end frame to 4096*/
:FUNCtion:WRECord:FEND? /*The query returns 4096*/

Rigol MSO1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Max Input Voltage	300 V (DC + AC peak)
Timebase Accuracy	± 50 ppm
Display	7-inch TFT LCD
Input Impedance	1 MΩ ± 2%
Trigger Modes	Edge, Pulse, Video, Slope, Pattern, Duration, Runt, Window, Nth Edge, Delay, Setup/Hold
Interfaces	USB Host, USB Device, LAN
Power Supply	100-240 VAC, 50/60 Hz, 50 VA max
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Waveform Capture Rate	50, 000 wfms/s (normal mode)
