Rigol MSO1104Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-61
:DECoder<n>:PARallel:PLOT
Syntax
:DECoder<n>:PARallel:PLOT <bool>
:DECoder<n>:PARallel:PLOT?
Description
Turn on or off the curve function of parallel decoding, or query the status of the curve
function of parallel decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
When this function is turned on, the variation trend of the bus data is displayed in vector
diagram form.
Return
Format
The query returns 1 or 0.
Example
:DECoder1:PARallel:PLOT ON /*Turn on the curve function*/
:DECoder1:PARallel:PLOT? /*The query returns 1*/
