RIGOL
Chapter 2 Command System
2-
184
MSO1000Z/DS1000Z Programming Guide
:TRIGger:TIMeout:TIMe
Syntax
:TRIGger:TIMeout:
TIMe <NR3>
:TRIGger:TIMeout:
TIMe?
Description
Set or query the time
out time in timeout trigger
. The default unit is s
.
Parameter
Name
Type
Range
Default
<NR3>
Real
16ns to
10
s
1
6n
s
Return
Format
The query returns t
he timeout time in scienti
f
ic notation.
Example
:TRIGger:TIMeout:
TIMe 0.002
/*
Set the timeout ti
me to 2ms*/
:TRIGger:TIMeout:
TIMe?
/*
The query returns 2.000000e-
03*/
199
201
Table of Contents
Guaranty and Declaration
3
Document Overview
4
Table of Contents
5
Chapter 1 Programming Overview
11
To Build Remote Communication
12
Remote Control Methods
14
SCPI Command Overview
15
Syntax
15
Symbol Description
15
Parameter Type
15
Command Abbreviation
16
Chapter 2 Command System
17
Autoscale
18
Clear
18
Run
18
Stop
18
Single
19
Tforce
19
Acquire Commands
20
Acquire:averages
20
Acquire:mdepth
21
Acquire:type
22
Acquire:srate
23
Calibrate Commands
24
Calibrate:quit
24
Calibrate:start
24
Channel<N> Commands
25
Channel<N>:Bwlimit
25
Channel<N>:Coupling
26
Channel<N>:Display
26
Channel<N>:Invert
27
Channel<N>:Offset
27
Channel<N>:Range
28
Channel<N>:Tcal
29
Channel<N>:Scale
30
Channel<N>:Probe
30
Channel<N>:Units
31
Channel<N>:Vernier
31
Cursor Commands
32
Cursor:mode
32
Cursor:manual
33
Cursor:track
40
Cursor:auto
45
Cursor:xy
49
Decoder Commands
53
Decoder<N>:Mode
53
Decoder<N>:Display
54
Decoder<N>:Format
54
Decoder<N>:Position
55
Decoder<N>:Threshold:channel1
56
Decoder<N>:Threshold:channel2
56
Decoder<N>:Threshold:channel3
56
Decoder<N>:Threshold:channel4
56
Decoder<N>:Threshold:auto
57
Decoder<N>:Config:label
57
Decoder<N>:Config:line
58
Decoder<N>:Config:format
58
Decoder<N>:Config:endian
59
Decoder<N>:Config:width
59
Decoder<N>:Config:srate
59
Decoder<N>:Uart
60
Decoder<N>:IIC
64
Decoder<N>:Spi
66
Decoder<N>:Parallel
72
Display Commands
78
Display:clear
78
Display:data
79
Display:type
80
Display:grading:time
81
Display:wbrightness
81
Display:grid
82
Display:gbrightness
82
Etable Commands
83
Etable<N>:Disp
83
Etable<N>:Format
83
Etable<N>:View
84
Etable<N>:Column
84
Etable<N>:Row
85
Etable<N>:Sort
85
Etable<N>:Data
86
Function Commands
87
Function:wrecord:fend
87
Function:wrecord:fmax
88
Function:wrecord:finterval
88
Function:wrecord:prompt
88
Function:wrecord:operate
89
Function:wrecord:enable
89
Function:wreplay:fstart
90
Function:wreplay:fend
91
Function:wreplay:fmax
91
Function:wreplay:finterval
92
Function:wreplay:mode
92
Function:wreplay:direction
93
Function:wreplay:operate
93
Function:wreplay:fcurrent
94
IEEE488.2 Common Commands
95
Cls
95
Ese
95
Esr
96
Idn
96
Opc
96
Rst
96
Sre
97
Stb
97
Tst
97
Wai
97
LA Commands
98
La:active
98
La:autosort
99
La:digital<N>:Display
99
La:digital<N>:Position
100
La:digital<N>:Label
100
La:display
101
La:pod<N>:Display
102
La:pod<N>:Threshold
102
La:size
103
La:state
103
La:tcalibrate
104
MATH Commands
105
Math:display
106
Math:operator
106
Math:source1
107
Math:source2
108
Math:lsource1
108
Math:lsource2
109
Math:scale
109
Math:offset
110
Math:invert
110
Math:reset
111
Math:fft:source
111
Math:fft:window
111
Math:fft:split
112
Math:fft:unit
112
Math:fft:hscale
113
Math:fft:hcenter
114
Math:fft:mode
114
Math:filter:type
115
Math:filter:w1
116
Math:filter:w2
117
Math:option:start
117
Math:option:end
118
Math:option:invert
118
Math:option:sensitivity
119
Math:option:distance
119
Math:option:ascale
120
Math:option:threshold1
120
Math:option:threshold2
121
Math:option:fx:source1
121
Math:option:fx:source2
122
Math:option:fx:operator
122
MASK Commands
123
Mask:enable
123
Mask:source
124
Mask:operate
124
Mask:mdisplay
125
Mask:sooutput
125
Mask:output
126
Mask:X
126
Mask:y
126
Mask:create
127
Mask:passed
127
Mask:failed
127
Mask:total
127
Mask:reset
127
Measure Commands
128
Measure:source
132
Measure:counter:source
132
Measure:counter:value
133
Measure:clear
133
Measure:recover
133
Measure:adisplay
134
Measure:amsource
134
Measure:setup:max
135
Measure:setup:MID
135
Measure:setup:min
136
Measure:setup:psa
136
Measure:setup:psb
137
Measure:setup:dsa
137
Measure:setup:dsb
138
Measure:statistic:display
138
Measure:statistic:mode
139
Measure:statistic:reset
139
Measure:statistic:item
140
Measure:item
141
Reference Commands
142
Reference:display
142
Reference<N>:Enable
142
Reference<N>:Source
143
Reference<N>:Vscale
143
Reference<N>:Voffset
144
Reference<N>:Reset
144
Reference<N>:Current
144
Reference<N>:Save
145
Reference<N>:Color
145
[:Source[<N>]] Commands
146
[:Source[<N>]]:Output[<N>][:State]
147
[:Source[<N>]]:Output[<N>]:Impedance
147
[:Source[<N>]]:Frequency[:Fixed]
148
[:Source[<N>]]:Phase[:Adjust]
148
[:Source[<N>]]:Phase:initiate
149
[:Source[<N>]]:Function[:Shape]
149
[:Source[<N>]]:Function:ramp:symmetry
150
[:Source[<N>]]:Voltage[:Level][:Immediate][:Amplitude]
150
[:Source[<N>]]:Voltage[:Level][:Immediate]:Offset
151
[:Source[<N>]]:Pulse:dcycle
151
[:Source[<N>]]:Mod[:State]
152
[:Source[<N>]]:Mod:type
152
[:Source[<N>]]:Mod:am[:Depth]
153
[:Source[<N>]]:Mod:am:internal:frequency
153
[:Source[<N>]]:Mod:fm:internal:frequency
153
[:Source[<N>]]:Mod:am:internal:function
154
[:Source[<N>]]:Mod:fm:internal:function
154
[:Source[<N>]]:Mod:fm[:Deviation]
155
[:Source[<N>]]:Apply
155
[:Source[<N>]]:Apply:noise
156
[:Source[<N>]]:Apply:pulse
156
[:Source[<N>]]:Apply:ramp
156
[:Source[<N>]]:Apply:sinusoid
156
[:Source[<N>]]:Apply:square
156
[:Source[<N>]]:Apply:user
156
Storage Commands
158
Storage:image:type
158
Storage:image:invert
158
Storage:image:color
159
System Commands
160
System:autoscale
160
System:beeper
161
System:error[:Next]
161
System:gam
161
System:language
161
System:locked
162
System:pon
162
System:option:install
162
System:option:uninstall
163
System:ram
163
System:setup
163
[:Trace[<N>]] Commands
164
[:Trace[<N>]]:Data
164
[:Trace[<N>]]:Data:dac16
165
[:Trace[<N>]]:Data:dac
166
[:Trace[<N>]]:Data:points
167
[:Trace[<N>]]:Data:points:interpolate
167
[:Trace[<N>]]:Data:value
168
[:Trace[<N>]]:Data:load
168
Timebase Commands
169
Timebase:delay:enable
169
Timebase:delay:offset
170
Timebase:delay:scale
171
Timebase[:Main]:Offset
172
Timebase[:Main]:Scale
173
Timebase:mode
173
Trigger Commands
174
Trigger:mode
174
Trigger:coupling
175
Trigger:status
175
Trigger:sweep
175
Trigger:holdoff
176
Trigger:nreject
176
Trigger:position
177
Trigger:edge
178
Trigger:pulse
180
Trigger:slope
184
Trigger:video
189
Trigger:pattern
192
Trigger:duration
195
Trigger:timeout
199
Trigger:runt
201
Trigger:windows
205
Trigger:delay
208
Trigger:shold
212
Trigger:nedge
215
Trigger:rs232
217
Trigger:IIC
222
Trigger:spi
226
Waveform Commands
232
Waveform:source
233
Waveform:mode
234
Waveform:format
234
Waveform:data
235
Waveform:xincrement
238
Waveform:xorigin
238
Waveform:xreference
239
Waveform:yincrement
239
Waveform:yorigin
239
Waveform:yreference
240
Waveform:start
240
Waveform:stop
241
Waveform:preamble
242
Chapter 3 Programming Demos
243
Programming Preparations
244
Excel Programming Demo
245
Matlab Programming Demo
249
Labview Programming Demo
251
Visual Basic Programming Demo
255
Visual C++ Programming Demo
257
