Rigol MSO1104Z Programming Guide

RIGOL Chapter 2 Command System
2-34 MSO1000Z/DS1000Z Programming Guide
:CURSor:XY:BX
Syntax
:CURSor:XY:BX <x>
:CURSor:XY:BX?
Description
Set or query the horizontal position of cursor B in the XY cursor measurement mode.
Parameter
Name
Type
Range
Default
<x>
Integer
5 to 394
300
Explanation
In the XY timebase mode, the horizontal and vertical positions of the cursor are defined
by the pixel coordinate of the XY display area. The pixel coordinate of the screen ranges
from (0,0) to (400,400). Wherein, (0,0) is located at the right top corner and (400,400) is
located at the left bottom corner. The horizontal and vertical pixel ranges are both from 0
to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:XY:BX 200 /*Set the horizontal position of cursor B to 200*/
:CURSor:XY:BX? /*The query returns 200*/
:CURSor:XY:AY
Syntax
:CURSor:XY:AY <y>
:CURSor:XY:AY?
Description
Set or query the vetical position of cursor A in the XY cursor measurement mode.
Parameter
Name
Type
Range
Default
<x>
Integer
5 to 394
100
Explanation
In the XY timebase mode, the horizontal and vertical positions are defined by the pixel
coordinate of the XY display area. The pixel coordinate of the screen ranges from (0,0) to
(400,400). Wherein, (0,0) is located at the right top corner and (400,400) is located at the
left bottom corner. The horizontal and vertical pixel ranges are both from 0 to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:XY:AY 200 /*Set the vertical position of cursor A to 200*/
:CURSor:XY:AY? /*The query returns 200*/

Rigol MSO1104Z Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Max Input Voltage	300 V (DC + AC peak)
Timebase Accuracy	± 50 ppm
Display	7-inch TFT LCD
Input Impedance	1 MΩ ± 2%
Trigger Modes	Edge, Pulse, Video, Slope, Pattern, Duration, Runt, Window, Nth Edge, Delay, Setup/Hold
Interfaces	USB Host, USB Device, LAN
Power Supply	100-240 VAC, 50/60 Hz, 50 VA max
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Waveform Capture Rate	50, 000 wfms/s (normal mode)
