MSO8000 Quick Guide 7
English
Figure 2 Rear Panel
Table 2 Rear Panel Description
No.
Description
1
Handle
2
LAN Interface
3
USB DEVICE Interface
4
USB HOST Interface
5
HDMI Video Output
6
Reference Clock Input/Output
7
EXT Trigger Input
8
Trigger Output Interface
9
Kensington Security Lock Hole
10
Fuse
11
AC Power Cord Connector
1 2 3 4 5
11 10 9 8 7 6
