22 Fan Convector Manual
OperangtheTimer(s)(FC824):
NOTE 
Before operang the Timer(s), the clock me must be
correct, and a starng me and nishing me for the
Timer(s) must be programmed. The two Timers
operate in the same way. This heater will begin
operang before the programmed starng me in
order for the room to reach the temperature seng
by the programmed starng me.
1. To select the Timer(s) to commence heang:
Check that the me shown on the Digital Display is
correct. Check the ON and OFF mes for both Timers.
2. Press the ONOFF buon to operate the heater:
The On indicator will glow green and the heater will
begin to operate. Select the desired temperature
seng.
3. Press the Timer 1 and On Timer 2 buon(s). The
Timer indicator(s) will glow and the heater will remain
on standby unl one hour prior to the me
programmed into the selected Timer(s). When this
me is reached, the Timer indicator will ash and the
heater will operate. The ON indicator glows red when
the heater commences operaon.
The heater can be operated to alternate between
Timers automacally during cold weather by selecng
Timer 1 and Timer 2 together. Both Timer indicators
will glow. The appliance will remain on standby at
intervals between the programmed nishing and
starng mes of each Timer. While the heater is
operang during programmed intervals the Timer
indicator will ash.
NOTE 
If there is a power failure, the system memory will
retain the Timer programs and the clock will stop at
when the power goes o. The clock will start keeping
me again when the power returns but will have to be
reset to the correct me.
OverrideFuncon:
NOTE 
This funcon is intended to be used to manually
override the current operaon of the heater while it is
in Timer mode. For example, if the heater is in standby
(between the end me and start me of the Timer),
and the Override buon is pressed, then the heater
will operate and heat the room. If the heater is in
operaon in Timer mode, then pressing the Override
buon will turn the heater OFF.
To operate the Override simply press the Override
buon. The Override indicator will ash.
To manually deacvate the Override simply press the
Override buon again. The Override indicator will go
out, and the heater will return to standby mode or
ON mode depending on the programmed mes.
NOTE
The heater will connue to operate on Override unl
the Override buon is pressed again, or one of the
Timers takes over the operaon of the appliance. This
means that the Override mode will automacally
drop out if a programmed Starng me is reached.
The appliance will then return to operang at mes
programmed into the Timer(s).
