Infinity REU-V1616W / REU-V1620W / REU-V2018W / REU-V2020W- 16 - Issue 2 - 21/03/06 ©Rinnai
10. Remote Controls
Remote Controls
Remote Controllers are an optional extra. 'Standard' and ’Deluxe’ controllers can
be fitted.
Standard controllers allow temperature selection only. Deluxe controllers have
temperature selection, bath-fill and voice prompting functions. For detailed
information regarding controller operation refer to the 'How to use your water
heater' booklet supplied with the appliance. Other manufacturers' controllers are
NOT compatible with this appliance.
Standard Controller (Model MC-91Q)
Up to 3 Standard Controllers can be fitted to the appliance. They are normally
installed in the areas where the majority of hot water is used, for example, the
kitchen, bathroom, ensuite and laundry.
Deluxe Kitchen Remote Control (MC-70)and (BC-70A)
Deluxe controllers have 'Kitchen' (MC-70-2A) and 'Bathroom' (BC-70-2A) versions. 'Kitchen' controls are
intended for the Kitchen or other convenient area where the majority of hot water is used. Bathroom
Controllers are intended to be fitted in the bathroom or ensuite and allow the user to have a bath filled to
the required level and temperature automatically.
:
Positioning of Controllers
Controllers must be installed in shaded and clean locations. They should be fitted out of reach of children
(suggested height from floor at least 1500mm). Controllers are water resistant, however, durability is
improved when positioned outside the shower recess or at least 400mm above the highest part of a sink,
basin or bath.
Up to three ’Deluxe’ Controllers
can be connected
Kitchen Bathroom Ensuite
MC91Q-2A
MC91Q-2A
MC70-2A BC70-2A
MC70-2A BC70-2A MC91Q-2A
195
97
22
BC-70-2A
120
90
20
MC-91Q-2A
