Infinity REU-V1616W / REU-V1620W / REU-V2018W / REU-V2020W- 2 - Issue 2 - 19/04/06 ©Rinnai
2. Specifications
Note 1: The default factory setting is 50°C or 55º C for REU-V1616W / REU-V1620W. The unit can be ordered from
Rinnai to be pre-set to any of the other temperatures listed. The unit can be pre-set to any of the temperatures
listed by a suitably qualified person. Controllers are available with default temperatures up to 75º C. When
fitted with controllers, only temperatures not exceeding the default temperatures can be selected. When fitted
without controllers, the unit will deliver water at the default temperature.
Type of appliance Temperature controlled continuous flow gas hot water system
Operation With / without remove controls, mounted in kitchen, bathroom etc
Exhaust system Forced Flue
Rinnai model number REU-V1616W / REU-V1620W
Installation Externally mounted
Dimensions Width - 350 mm
Height - 530 mm
Depth - 170 mm
Weight 16 kilograms
Gas consumption (Min. / Max.) Natural gas : 125 ~ 18 MJ/h
Propane gas : 125 ~ 18 MJ/h
Output (kW) (Min. / Max.) 27.9 / 4.0
Connections Gas connection - R3/4 (20A)
Cold water connection - R1/2 (15A)
Hot water connection - R 1/2 (15A)
Ignition system Direct electronic ignition
Electrical consumption Normal - 47 W
Standby - 6 W (with 1 remote control)
Anti-frost protection - 74 W
Hot water capacity (Raised 25°C) 2.3 to 16 L/min
Thermal efficiency 80%
NOXaf 35 ppm
Temperature range (with remote) Kitchen controller : 37 ~ 55°C
Bathroom controller: 37 ~ 50°C
Default temperature control
(without remote)
40°C, 43°C, 50°C, 55°C (factory setting), 65°C, 75°C
(set by combination of dip switches on PCB)
Water Temperature control Simulation feedforward and feedback
Water flow control Water flow sensor, Electronic water flow control device
Minimum operating water pressure 10 kPa
Nominal operating water pressure 100 kPa ~ 830 kPa
Minimum operating water flow 2.4 L/min
Maximum operating water flow 16 L/min (REU-V1616W) / 20 L/min (REU-V1620W)
Power supply Appliance - AC 240 Volts 50 Hz
Remote control - DC 12 Volts (Digital)
Safety device Flame failure - flame rod
Boil dry - water flow sensor
Remaining flame (OHS) - 97°C bi-metal switch
Over temperature - 95°C lockout thermistor
Fusible link - 129°C Thermal fuse
Pressure relef valve - Opens 2060 kPa, Closes: 1470 kPa
Combustion fan rpm check - Integrated circuit system
Over current - Glass fuse (3 Amp)
Deluxe remote control (optional) Kitchen control - MC-91Q-2A - MC70-2A
Bathroom control - MC91Q-2A - BC70-2A
Second bathroom control - MC91Q-2A
Cable (optional) Non-polarized two core cable
