Rinnai REU-VRM3237WC Service Manual

Infinity REU-VR3237WG / HD250e REU-VRM3237WC - 38 - Issue 1 - 19/05/09 ©Rinnai
(IIHFWLYH
NO DESCRIPTION RA CODE 11 DIGIT CODE VR3237WG VR3237WG-50 VRM3237WC
405 WATER FLOW SENSOR WITH VALVE HEATER 92087064 301-163-000 1 1 1
406 RECTIFIER WATER 92093552 330-107-000 1 1 1
407 BYPASS SERVO ASSY 92087072 301-158-000 1 1 1
408 STOP BRACKET 512-401-000 22 2
409 WATER FLOW SERVO COVER 098-1445000 1 1 1
410 OUTLET WATER 3/4 92093807 333-450-000 1 1 1
411 PLUG BAND 553-043-000 1 1 1
412 VALVE PRESS RELIEF 92099944 337-152-000 1 1 1
413 STOP BRACKET 512-406-000 1 1 1
700 PCB MAIN 92099918 210-909-000 1 1
700 PCB MAIN -50-AK 92099948 210-910-000 1
701 SURGE ARRESTOR 92093699 210-605-000
1 1 1
702 PCB COVER-FRONT 098-1869000 1 1 1
703 PCB
COVER-SIDE 098-1844000 1 1 1
704 IGNITOR BRACKET 538-0396000 1 1 1
705 SPARKER 92095026 261-157-000 1 1 1
706 LEAD HT 92092253 203-828-000 1 1 1
707 IGNITOR COVER 098-1845000 1 1 1
708 HEATER A-FROST 92093295 235-376-000 1 1 1
709 BRKT HEATER 92093301 538-493-000 22 2
710 BRKT HEATER B 92096225 537-0440000 1 1 1
711 ANTI FROST HEATER CLIP 537-215-000 1 1 1
712 HEATER WATER FLOW 92092262235-369-000 1 1 1
714 FUSE THERMAL 92090175 290-1273000 1 1 1
715 THERMAL FUSE CLIP
553-055-000 9 9 9
716 THERMISTOR 1 9
2095030 233-246-000 22 2
717 THERMISTOR CLIP 92083688 508-836-000 1 1 1
718 SWITCH THERMAL 92097187 234-444-000 1 1 1
720 HARNESS FUSE WITH HEATER 92094004 290-1396000 1 1 1
721 HARNESS POWER 92095038 204-0015000 1 1 1
722 HARNESS SPARKER 92095039 290-1398000 1 1 1
723 SENSOR HARNESS 92099951 290-1706000 1 1 1
724 ELEC CORD 92089051 206-226-000 1 1 1
725 HARNESS REMOTE 92095041 290-1399000 1 1 1
730 STATUS MONITOR BRACKET
537-0643000 1
731 RELAY 9209503
2210-810-000 1
732 HARNESS RELAY 92095033 290-1289000 1
800 SCREW 501-973-010 3 3 3
800 EARTH SCREW 501-889-000 1 1 1
801 WASHER 503-022-010 3 3 3
802 SCREW 501-0057000 22 2
803 WASHER 503-026-010 5 5 5
804 SCREW 501-0091000 8 8 8
805 SCREW 501-865-000 5 5 5
806 SCREW 501-737-000 1 1 1
807 SCREW 501-0092000 5 5 5
808 SCREW 501-0064000 22 2
809 SCREW 501-0093000 3 3 3
810 SCREW 501-295-000 1 1 1
811 O RING GAS CON 92072859 520-043-010 1 1 1
812 O RING IN/OUT WATER 92071182 520-049-010 3 3 3
813 O RING HEAT EXCH 92062199
520-048-010 1 1 1
814 O
RING HEAT EXCH 92062207 520-193-010 22 2
