Rinstrum R320 Communications Manual

Communications Manual Rev 3.10 Software Versions 3.xx
003R-618-310 Page 25
6. Reading Status and Error Codes
6.1. REG_SYSTEM_STATUS
This register contains status information about the indicator.
Bit(s) Field Description
31 to 18, 8, 5, 4 RESERVED Reserved for future use.
17 OverLoad The weight is above the maximum
allowable weight reading.
16 UnderLoad The weight is below the minimum allowable
weight reading.
15 Error Diagnostic error.
Check REG_SYSTEM_ERROR.
14 MenuActive Setup menus are active. Registers cannot
be written to using COMM.
13 Calibrating Unit is busy calibrating.
12 Motion Weight is not stable.
11 isCOZ The gross reading is within ± ¼ of a division
of true zero.
10 isZero The displayed weight is within the zero
'dead' band setting.
9 DisplayNet Display is showing NET value.
7 Output1 The setpoint weight is over the setpoint
target.
6 Output2 The setpoint weight is under the setpoint
target.
3 .. 0 InternalErrorCode Used for Calibration Errors, etc.
Table 6: Register REG_SYSTEM_STATUS Interpretation
The following table lists the values that the InternaErrorCode field may take. It lists
the error message that would be displayed on the indicator’s display if the operation
was being performed using the setup menus.
Display
Message
Code
Value
Description
no error 00 Last operation was successful.
(SPAN) (LO) 01 The load cell signal range (span) is too small for these
settings.
(SPAN) (HI) 02 The load cell signal range (span) is too large for these
settings.
(RES) (LO) 03
The scale build is configured for less than 100 graduations.
(RES) (HIGH) 04 The scale build is configured for more than 30,000
graduations.
(PT.TOO)
(CLOSE)
05 An attempt has been made to place a calibration point too
close to an existing calibration point.
06 The calibration (linearisation) point does not exist.
(LIN.PT) (LO) 07 An attempt has been made to place a linearisation point
below zero.
(LIN.PT) (HI) 08 An attempt has been made to place a linearisation point
above fullscale.
(RES) (LO)
The scale build is configured for less than 100 graduations.
(RES) (HIGH) The scale build is configured for more than 30,000
graduations.
