Communications Manual Rev 3.10 Software Versions 3.xx
Page 34
003R-618-310
10. Printing
10.1. Basic Operation
There are two non-volatile registers available for user programmable print strings.
REG_PROG_PRINT with a capacity 80 ascii(160 hex) characters including tokens.
REG_PROG_PRINT_SUMMARY with a capacity of 20 ascii(40 hex) characters
including tokens. The REG_PROG_PRINT register is used if
SERIAL:FORMAT:CUSTOM is selected.when prints are activated for SERIAL:TYPE
settings of AUTO, SINGLE and AUTO.PR.
When SERIAL:TYPE:PRINT is selected a short press of the print key uses
REG_PROG_PRINT as the source for printing while the
REG_PROG_PRINT_SUMMARY register is used when prints are activated by a
long press of the print key.
FACTRY:DEFLT resets REG_PROG_PRINT to the standard short print press
printing, while REG_PROG_PRINT_SUMMARY is reset to the standard long print
press printing. Alternatively the standard formats can be set by writing the default
print tokens (indicated below) to the registers REG_PROG_PRINT and
REG_PROG_PRINT_SUMMARY respectively.
10.2. Tokens Available for Printing
The following table lists the tokens available for printing:
Token Corresponding Print Feature
7F
H
Default Print String (short print press)
8F
H
Default Print String (long print press)
CF
H
Gross Weight
D0
H
Net Weight
D8
H
Tare_Weight
D9
H
Display Weight
F0
H
Count (if counting is turned on)
C0
H
Time
BF
H
Date
DA
H
Print Identifier
E8
H
Streaming Register Literal
E9
H
Streaming Register Raw
DB
H
Total Weight (total of Display Weight)
DD
H
Total Count (if counting is turned on)
DC
H
Items (No. of prints since last summary)
