Rinstrum R320 Communications Manual

Communications Manual Rev 3.10 Software Versions 3.xx
Page 40 003R-618-310
Register Code Type Example Description
REG_SPAN_MVV 0113
H
WEIGHT 000061A8 Calibrated Span
mV/V
REG_LIN1_WEIGHT ..
REG_LIN10_WEIGHT
0114
H
011D
H
WEIGHT 08000001 Weight at
Linearisation points
> 00100000 means
no point
REG_RESOLUTION 0122
H
OPTION 00000000 Resolution setting
REG_DECIMAL_PLACES 0128
H
OPTION 00000000 Decimal Point
position
REG_UNITS 0129
H
OPTION 00000000 Units selection
REG_CABLE_MODE 012A
H
OPTION 00000000 4/6 wire operation
REG_HIRES_MODE 012B
H
OPTION 00000000 High resolution
(x10) mode
REG_TRADE_USE 0130
H
OPTION 00000000 Trade or Industrial
operation
REG_FILTER 0131
H
OPTION 00000000 Filtering setting
REG_MOTION 0132
H
OPTION 00000000 Motion setting
REG_ZERO_RANGE 0133
H
OPTION 00000000 Zero range setting
REG_ZERO_TRACKING 0134
H
OPTION 00000000 Zero tracking setting
REG_ZERO_INIT 0135
H
OPTION 00000000 Initial zero operation
REG_ZERO_BAND 0136
H
LONG 00000000 Zero band setting
REG_AUTO_TARE_THRESH 0138
H
LONG 00000000 Automatic tare
threshold
REG_SERIAL_TYPE 0140
H
OPTION 00000000 Type of serial output
REG_SERIAL_FORMAT 0141
H
OPTION 00000000 Format of serial
output
REG_SERIAL_BAUD 0142
H
OPTION 00000000 Baud rate
REG_SERIAL_BITS 0143
H
BITFIELD 00000000 Parity and Stop bits
REG_SERIAL_ADDRESS 0144
H
BYTE 0000001F Network Address
REG_PRINTER_SEQUENCE 0145
H
EXECUTE Reset Printer Seq.
command
REG_PROG_PRINT 0146
H
BLOB 00D8000D000E… Programmable
Printing Short
REG_PROG_PRINT_SUMMARY 0147
H
BLOB 00D8000D000E… Programmable
Printing Long
REG_CLOCK 0150
H
STRING 16/10/2003 10:32 Full Date/Time
string
REG_CLOCK_FORMAT 0151
H
OPTION 00000000 Date format
selection
REG_DATA_DD 0152
H
USHORT 00000011 Date
REG_DATA_MM 0153
H
USHORT 0000000A Month
REG_DATE_YYYY 0154
H
USHORT 000007D3 Year
REG_TIME_HH 0155
H
USHORT 0000000A Hour
REG_TIME_MM 0156
H
USHORT 00000020 Minute
REG_TIME_SS 0157
H
USHORT 00000015 Second
REG_KEY_LOCK 0160
H
BITFIELD 00000000 Key locking
REG_USER_KEY_FUNC 0161
H
OPTION 00000000 Special Function
setting
REG_AUTO_OFF_TIME 0162
H
OPTION 00000000 Auto power off
setting
REG_BACKLIGHT 0163
H
OPTION 00000000 Backlight options
REG_REMOTE_KEY_FUNC 0164
H
OPTION 00000000 Remote key function
setting
REG_SETPT_TYPE_1 0170
H
OPTION 00000000 Setpoint 1 Type

Rinstrum R320 Specifications

General

Category	Accessories
Excitation Voltage	5 VDC
Type	Indicator
Display	20 mm high
Power	12-24 V DC
Operating Temperature	-10°C to +50°C
Load Cell Connection	4-wire
Communication Ports	RS-232, RS-485
