01/18 9
3 TECHNICAL SPECIFICATION
3.1 General
Description (symbol) Unit
Dimension : see chapter 11.4 Dimension FlexJet
page: 65
Weight (dry and without options) (m) : ~340 kg /~ 540 kg (FJ+)
Total weight (without options) (m) : ~ 750 kg / ~1200 kg (FJ+)
Quantity water tank : Max 400 l / Max. 550 l (FJ+)
Supply medium : Water
Maximum temperature medium : 60 °C
Standard colours : Yellow/gray or white/gray
Type tyre : 155R13C 89/91N
Recommended tyre tension : 4,5 bar
Total length high-pressure hose : 40-80 m
Diameter high-pressure hose : 1/2”
Total length supply hose : 35 m
Diameter supply hose : 3/4”-5/8”
Place type plate :
Place chassis number :
Quantity oil tank : 5,5 l
Supply medium oil tank : Hydraulic oil HESTIA 46
Sound level and measure position : see chapter 12 Appendix page: 65
Year of construction (month/year) : 01/18
For more data FlexJet+ see chapter 11.8 COC page: 69
