01/18 41
7OPTIONS
7.1 Hydraulic reel control
By means of pushing the control lever upwards or downwards the high-pres-
sure hose can be unrolled or rolled up. Due to the proportional functioning of
this valve you can also control the speed of the reel. By putting the lever into
the position you can unroll the hose manually.
Attention!
Never block the lever and always control it with one hand
while guiding the high-pressure hose by means of the hose
guide with the other hand to the required place.
A Wind the hose
B Reel locked
C Unwind the hose
D Reel “out of gear”
E Reel rotates faster
F Reel rotates slower
7.2 Hose guide
Purpose:
To guide the HP hose into the sewer.
To wind the HP hose on the reel drum.
Use:
• Only use the hose guide in his lower position (horizontal).
• Put the end of the hose through the opening of the hose guide.
• By moving the hose guide to the right and left, you can wind the HP
hose fluently on the reel drum.
• After use, put the hose guide vertical and lock the support. Clamp the
hose guide.
Advantage
•No dirty hands
• Hose lives longer
• More freedom of movement
•Security
• Hose stays cleaner
