5. Tension the brake rod. Turn it clockwise until the hinged lever touches
the brake cylinder without clearance.
6. Lock the brake rod by turning the lock nut against the fork of the brake
rod.
7. Check the functioning of the brakes by means of a brake test.
8. Check the brakes on overheating (= brakes over tightened).
9. If the brakes become overheated, readjust the brake system once
more.
8.6 Replacing lamps in the lighting unit
If the bulbs burn than these are hot and also their environment. Turn
off the lights and let them cool down before replacing it.
• Always turn off the lights and turn off the ignition before you replacing
bulb lights .
• Never hold the glass bulbs with your fingers.
• Always replace a defective bulb with a new one of the same type.
• Before replacing a light bulb, check it if it’s operates correctly.
• The back cover must be removed to place of the defected bulbs.
• Fog and reverse lamp can be replaced without removing the back cov-
er!
Proceed as follows:
1. Screw off the back cover at point A
and also in some models at point B
(2x).
2. Remove the back cover.
• Optionally, the connector plug can
also be detach.
3. Place the cover on the ground.
4. Replace the defective bulb(s).
5. Assemble everything in reverse se-
quence.
