Rioned flexJET+ - Page 26

01/18 22
Oil Alert lamp petrol engine:
Execution: B&S Honda 20hp Honda 24hp
Switch: Pressure Level Level
Standard, without
control box
Oil alert engine lamp
lights when “ignition
on”.
Lamp is off at “igni-
tion on”
not applicable
Lamp goes out with
running engine.
Lamp is off with run-
ning engine.
not applicable
No pressure: lamp
burns; engine falls off.
Lamp burns with low
oil level; engine falls
off.
not applicable
Standard, with con-
trol box.
Lamp burns with
“Ignition on”.
Lamp is off at “igni-
tion on”
Lamp is off at “igni-
tion on”
Lamp goes out with
running engine.
Lamp is off with run-
ning engine.
Lamp is off with run-
ning engine.
No pressure: lamp
burns; engine falls off.
Scheme 005.000.280
No pressure: lamp
burns; engine does
not falls off.
Scheme 005.000.274
Lamp burns at low oil
level; engine does
not falls off.
Scheme 005.000.274
5-channel remote
(small print).
Lamp is off at “ignition
on”
Lamp is off at “igni-
tion on”
Lamp is off at “igni-
tion on”
Lamp goes out with
running engine.
Lamp is off with run-
ning engine.
Lamp is off with run-
ning engine.
No pressure: lamp
burns; engine falls off.
Scheme 005.000.394
Lamp burns with low
oil level; HP close,
throttle close, engine
does not falls off
(equal with run dry).
Scheme 005.000.395
Lamp burns with low
oil level; HP close,
throttle close, engine
does not falls off
(equal with run dry).
Scheme 005.000.395
Execution: B&S Honda
20hp
Honda 24hp
Switch: Pressure Level Level
Standard, with-
out control box.
Ignition on:
(Oil alert on engine)
not applicable
Engine runs: not applicable
Low oil level:
Engine stop
not applicable
Standard, with
control box.
Ignition on:
Engine runs:
Low oil level: Engine stop
No engine
stop
No engine stop
