01/18 70
General construction characteristics
1. Number of axles: … and wheels: … 1 / 2
1.1 Number and position of axles with twin wheels: -
Main dimensions
4. Wheelbase: 2220 mm
4.1 Axle spacing: -
5. Length: 3170 mm
6. Width: 1410 mm
7. Height: 1330 mm
10. Distance between the centre of the coupling device and the rear
end of the vehicle:
3140 mm
11. Length of the loading area: -mm
12. Rear overhang: 920 mm
Masses
13. Mass of the vehicle in running order: 420 kg
13.1 Distribution of this mass amongst the axles: 390 kg
13.2 Actual mass of the vehicle: 420 kg
16. Technically permissible maximum masses:
16.1 Technically permissible maximum laden mass: 1200 kg
16.2 Technically permissible mass on each axle: 1350 kg
16.3 Technically permissible mass on each axle group: -
19. Technically permissible maximum static mass on the coupling
oint of a semi-trailer or centre-axle trailer:
100 kg
Maximum speed
29. Maximum speed : 140 km/h
Axles and suspension
30.1 Track of each steered axle: 1200 mm
30.2 Track of all other axles: -
31. Position of retractable axle(s): -
32. Position of loadable axle(s): -
34. Axle(s) fitted with air suspension or equivalent: no
35. Tyre/wheel/rim combination: 155R13 C, 89/91N, 4½Jx13H2
Brakes
36. Trailer brake connections: mechanical
Bodywork
38. Code for bodywork: DC
Coupling device
44. Approval number or approval mark of coupling device: E1-55R-01-0159
45.1 Characteristics values: D:14,95kN / V:- / S:120kg / U:-
Miscellaneous
50. Type-approved according to the design requirements for
trans
ortin
dan
erous
oods:
yes/class(es):…………………………./
no
51. For special purpose vehicles: designation in accordance with
Annex II Section 5:
-
52. Remarks: -
