Before starting
Right hand wing panel
Left hand
wing panel
Fin
Fuselage
Remove the protective wrapping and identify the airframe components. The wing panels include the ailerons hinged and
The tailplane includes the elevator hinged and fitted. The fin includes the rudder hinged and fitted. The fuselage includes
mount and noseleg bracket fitted and the control pushrods.
Open the large accessory bag and identify the Contents.
Keep the smaller bags sealed until their parts are required
for use, this will prevent losing any item.
fitted.
the engine
A Fuel tank with accessories and
foam packing
B Nose wheel and pair of
main wheels
C Selection of spare wood for any
minor repairs
D Engine Spinner and securing
screws
E Various mounting hardware and
moulded components
F Wing retaining elastic bands
G Main undercarriage legs
H Nose wheel undercarriage leg
J Aileron pushrods
K Seif adhesive covering repair
strip
L Aileron servo mounting tray
and bearers
Further items and tools required
In order to build your Trainer 40 model a selection of hand
tools and adhesives will be required.
These include:
Steel ruler
Cyanoacrylate adhesive medium viscosity
5 minute epoxy adhesive
30 minute epoxy adhesive
Pliers
Side cutters
Modelling knife
Small file
Small allen key
Feit tip pen
Ball point pen
Masking tape
Pin chuck with 1.5mm and 2mm drills
Small cross point screwdriver
