Rittal RIMATRIX5 PMC12 User Manual

UPS-Manual
31
EN
Battery Bank Dimensions
Convertible(Rack/Tower)
BBC20J0007(20pcs 12V/7AH)
440x133x660(3U)
Battery Bank Net Weight
Convertible(Rack/Tower)
BBC20J0007 w/o bat./with bat.
18 kg/ 68 kgs
ENVIRONMENT
Operating Temperature 0° C to 40° C
Temperature Warning
The battery design life is based on a
temperature of 25° C. Ambient
temperature above this range will reduce
battery life.
Altitude
0~2000 m up to 40° C,
3000 m up to 35° C
Humidity 90% RH Maximum, Non-Condensing
Noise <50 dB (at 1 meter)
COMPUTER INTERFACE
Interface Type Standard RS232 Interface, USB & EPO
Communication Slots SNMP/WEB Card
SAFETY CONFORMANCE
Quality Assurance ISO9001 Certified Company
Safety Standard EN62040-1, UL1778
EMC Standard
EN62040-2, EN61000-3-2, EN61000-3-3,
FCC Class A
Marks
CE, WEEE
* (160~176Vac at <75% load)
