11. Technical Data
Model 4,5 kVA 6 kVA
INPUT
Voltage Window 160~280 VAC*
Frequency 45 ~ 65 Hz
Phase/Wire Single, Line + Neutral + Ground
Power Factor Up to 0.99 at 100% Linear Load
Current THD <6% at 100% Linear Load
OUTPUT
Voltage Window 220/230/240 VAC Selectable
Voltage Adjustment
0%; ±1%; ±2%; ±3%
Voltage Regulation
±2%
Capacity 4500 VA/3150 W 6000 VA/4200 W
Rated Power Factor 0.7 Lagging
Wave Form
Sine Wave, THD<3%(no load to full Linear
load)
Frequency Stability ±0.2%(Free Running)
Frequency Regulation ±1%; ±3%
Transfer Time 0ms
Efficiency(AC to AC,
Normal)
Up to 90%
Efficiency(AC to AC, ECO)
Up to 97%
Autonomy at load 50% 100% 50% 100%
1 Battery 20 Min. 9 Min. 18 Min. 8 Min.
2 Batteries 48 Min. 23 Min. 45 Min. 20 Min.
3 Batteries 95 Min. 39 Min. 74 Min. 33 Min.
DC Start Yes
BATTERY
Type
Sealed Lead Acid Maintenance Free
12 V / 7 AH
Quantity 20 pcs
Voltage 240 VDC
Recharge Time 4 hours to 90%
DISPLAY
Status On LED + LCD
Line Mode, Backup Mode, ECO Mode,
Bypass Supply, Battery Low, Battery
Bad/Disconnect, Overload, Transferring with
interruption & UPS Fault.
Readings on LCD
Input Voltage, Input Frequency, Output
Voltage, Output Frequency, Load Percentage,
Battery Voltage & Inner Temperature.
Self-Diagnostics
Upon Power-on, Front Panel Setting &
Software Control, 24-hour routine checking
ALARMS
Audible and Visual
Line Failure, Battery Low, Transfer to Bypass,
System Fault Conditions
PHYSICAL
Dimensions(WxDxH)mm 440x88x660(UPS Module)
Input/Output Connection Hardwire
External Battery Connection
Plug-in & Play
Net Weight(Kgs) 24(UPS Module)
