RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
115
1H)
• 1:1 Connection
• 1:n Connection
• The 5V output (Pin #6) on the Display is the power for the Siemens AG’s PROFIBUS
connector. Do not use it for other devices.
• In COM on the GP-4107, the SG and FG terminals are isolated.
T/R(B)
T/R(A)
SG
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
External Device
Terminal block
Shield
Signal name
Display
Pin
Signal name
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
LINE(+)
LINE(-)
3
8
1
2
5
4
6
7
9
Shell
Display side
D-Sub 9pin (plug)
T/R(B)
T/R(A)
SG
T/R(B)
T/R(A)
SG
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
External Device
Terminal block
External Device
Terminal block
Shield
Shield
Signal name Signal name
Display
Pin
Signal name
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
LINE(+)
LINE(-)
3
8
1
2
5
4
6
7
9
Shell
Display side
D-Sub 9pin (plug)
