Eagle Instruction Manual Appendix G: Five-Gas and Six-Gas Models • 72
Appendix G: Five-Gas and Six-Gas Models
Overview
The standard Eagle gas monitor includes one to four channels and
displays gas readings for all channels simultaneously. Some Eagle
models include five or six channels; however, the Eagle is only
capable of displaying gas readings for four of the channels at any one
time.
Five- and six-gas Eagle models include up to four sensors in the
standard sensor block. The additional sensor(s) are mounted in the
front half of the instrument case and are wired to sockets EC3
(channel 5) and EC4 (channel 6) on the analog PCB.
NOTE: The data logging accessory is not available for the Eagle’s
five- and six-gas models. This is also true for five- and six-gas
models with four or less active channels.
Displaying Additional Channels
The normal screen displays a cursor (>) at the far left to indicate that
additional channels can be displayed.
• A cursor to the left of the last channel displayed indicates that
additional channels are available after the currently displayed
channels. Press the SHIFT/▼ button to display the remaining
channels.
• A cursor to the left of the first channel displayed indicates that
additional channels are available before the currently displayed
channels. Press the AIR/▲ button to display the remaining
channels.
CH
4
OY
CO
H
2
S
X
2
0.9
0
0
0.0
L
V
P
P
P
P
M
M
E
O
L
L
%
%
>
CH
4
OY
CO
H
2
S
X
2
0.9
0
0
0.0
L
V
P
P
P
P
M
M
E
O
L
L
%
%
>
