RKS MC3 - Handlebar and Stem Assembly

12
5. Open the seat post quck release
lever(Fg. 8). Insert the seat post nto the
seat tube to a sufficent depth so that the
mnmum nserton lne s no longer showng.
6. When you are satsfied wth the heght of the seat post, close the seat
post quck release lever. The tghtness of the lever s adjusted by rotatng
the adjustment nut opposte the quck release lever. Turn the nut by hand
to adjust the tenson whle holdng the lever stable.
Step 3: Handlebar & Handlebar Stem Assembly(refer to fig. 9 and 10)
As an usual stuaton, n our factory, the handlebar have been pre-
assembled together wth brake levers, shfter levers and grps. Be sure
that the longer cable s fixed to the rght lever (rear brake) and shorter
cable to the left (front brake), or accordng to your local rule and practce
(Note: In some area, such as UK, the cables are requred to be arranged
n the opposte way).
Snce your cycle may be fitted wth an adjustable, a standard stem or an
A- head stem(refer to fig.9 ), you must always check that all the bolts are
tght before cyclng. Based on the stuaton of standard handlebar stem,
please follow the nstructon below:
1. Push the handlebar stem nto the fork tube (head of the frame ) to the
mnmum heght lne that s marked on the sde of the handlebar stem. It
mght be necessary to loosen the expender bolt so that the stem can slde
nto the fork tube, untl you get your desred heght of the handlebar stem
