13
Mode 1 Mode 2 8 bit Value Function Type of control
channel channel channel
12 12 10 Colours macros - CMY and color wheel
48-55 Macro 6 step
56-63 Macro 7 step
64-71 Macro 8 step
72-79 Macro 9 step
80-87 Macro 10 step
88-95 Macro 11 step
96-103 Macro 12 step
104-111 Macro 13 step
112-119 Macro 14 step
120-127 Macro 15 step
128-135 Macro 16 step
136-143 Macro 17 step
144-151 Macro 18 step
152-159 Macro 19 step
160-167 Macro 20 step
168-175 Macro 21 step
176-183 Macro 22 step
184-191 Macro 23 step
192-199 Macro 24 step
200-207 Macro 25 step
208-215 Macro 26 step
216-223 Macro 27 step
224-231 Macro 28 step
232-239 Macro 29 step
240-247 Macro 30 step
248-255 Macro 31 step
13 13 11 Effect wheel
0-70 Full beam step
71-180 Beam shaper proportional
181-255 Frost filter proportional
14 14 12 No function
15 15 13 Shutter,strobe
0-31 Shutter closed step
32-63 No function (shutter open) step
64-95 Strobe-effect from slow to fast proportional
96-127 No function (shutter open) step
128-159 Pulse-effect in sequences proportional
160-191 No function (shutter open) step
192-223 Random strobe-effect from slow to fast proportional
224-255 No function (shutter open) step
16 16 14 Dimmer intensity
0-255 Gradual adjustment of the dimmer intensity proportional
from 0 to 100%
