12
5. DMX PROTOCOL
Mode 1 Mode 2 8 bit Value Function Type of control
channel channel
1 1 1 Pan
0-255 Pan movement by 530° proportional
2 3 2 Tilt
0-255 Tilt movement by 280° proportional
3 2 Pan fine
0-255 Fine control of pan movement proportional
4 4 Tilt fine
0-255 Fine control of tilt movement proportional
5 5 3 Speed of PAN/TILT movement
0 Max. speed (tracking mode) step
1-249 From max. to min.speed (vector mode) proportional
250-255 Max. speed,black-out while PAN,TILT
moving orcolor changes (tracking mode) step
6 6 4 Lamp on/off,reset,fans speed control
0-127 From max.speed of fan to min. speed of fan proportional
128-139 Lamp on,reset step
140-229 No function step
230-239 Lamp off after 3 sec step
240-255 No function step
7 7 5 Colours
0-17 Open/white step
18-35 Red step
36-53 Blue step
54-72 Green step
73-90 CTF 3200 K step
91-108 CTF 5600 K step
109-127 UV filter step
128-190 Forwards rainbow effect from fast to slow proportional
191-192 No rotation step
193-255 Backwards rainbow effect from slow to fast proportional
8 8 6 Cyan
0-255 Cyan ( 0- white, 255 - full cyan ) proportional
9 9 7 Magenta
0-255 Magenta ( 0-white, 255-full magenta ) proportional
10 10 8 Yellow
0-255 Yellow (0-white,255-full yellow) proportional
11 11 9 Speed of CMY and dimmer
0-255 From max. speed to min. speed proportional
12 12 10 Colours macros - CMY and color wheel
0-7 Off step
8-15 Macro 1 step
16-23 Macro 2 step
24-31 Macro 3 step
32-39 Macro 4 step
40-47 Macro 5 step
