To assign an e󰀨ect to the Jog-wheels and faders
1.Touch desired e󰀨ect. Buttons (8/10/16/18) which activate jog-wheels (23/24/25/26) and buttons (20/22), which
matches faders (27/28) will start to ash.
2.Press desired button and selected e󰀨ect will be assigned to its jog-wheel (fader).
Assigned e󰀨ect is displayed in a yellow colour, free e󰀨ects stay in a white colour.
3.Repeat steps 1 and 2 for needed e󰀨ects.
4.Touch the [cancel] icon and than [back arrow] icon. The screen with e󰀨ect faders will appear.
E.g.
Sensitivity of the jog-wheels assigned to the e󰀨ects can be set at three levels: low, medium and high.
The levels of the sensitivity are marked in colour on the screen:
low level - green slider
medium level -yellow slider
high level- red slider
In order to switch a jog-wheel to desired level of sensitivity, press and hold its activating button (8/10/16/18)
until the colour of fader is changed.
E󰀨ects assigned to the four jog-wheels and two faders have a priority over DMX values coming from a DMX
controller.
Only e󰀨ects assigned to the jog-wheels will
appear on this screen.
E󰀨ects assigned to faders (27/28) will not
be shown.
