Robe ROBIN BMFL LightMaster Side - Menu Functions Mapping

17
5.1 Menu Functions Mapping
By entering the menu you can assign e󰀨ects from the list of available e󰀨ects to the jog-wheels and faders.
The item All - releases all assigned e󰀨ects at one go.
List of available e󰀨ect channels depends of used moving head:
Fixture E󰀨ect Available DMX values
Robin BMFL FollowSpot
Dimmer 0-255
Iris 0-179
Focus 0-255
Zoom 0-255
L Frost 0-254
M Frost 0-254
H Frost 0-254
Color 1 0,130-189
Color 2 0,130-189
Cyan 0-255
Magenta 0-255
Yellow 0-255
CTO 0-255
Fixture E󰀨ect Available DMX values
Robin BMFL Spot
Dimmer 0-255
Iris 0-179
Focus 0-255
Zoom 0-255
L Frost 0,1-50
M Frost 0,87-136
H Frost 0,173-222
Color 1 0,130-189
Color 2 0,130-189
Cyan 0-255
Magenta 0-255
Yellow 0-255
CTO 0-255
DgW. pos 0-127
DgW. r1 0-255
DgW. r2 0-255
RGW 1 0,32-59
RGWr 1 0-255
RGW 2 0,32-59
RGWr 2 0-255
Prism 0-127
Pris r 0-255
