7.4 Weight transfer system
Use the weight transfer system to increase traction on the wheels or the mowing units.
• Push the weight transfer switch forwards
to transfer the weight to the wheels and,
therefore, increase traction.
• Push the weight transfer switch (1)
backwards to transfer the weight to the
mowing units
7.5 Operating the free-wheeling mechanism
Your machine is provided with special tools required to enable free-wheeling of the front wheel motors.
Follow this procedure if your machine breaks down while on an incline.
WARNING
• With the free-wheeling tools installed, the machine will have unrestricted motion. If machine is on an incline
it may free-wheel out of control after unlocking the wheel motors. Prevent machine from free-wheeling by
mounting a rigid tow bar onto another machine.
• Do not tow the machine more than necessary. Towing the machine may cause damage to the hydraulic
system. The machine can be towed over a maximum distance of 1,000 m at a maximum speed of 2 km/h.
Turning on the free-wheeling mechanism
Before you begin:
1. Block the wheels.
2. Attach the mower (1) onto another
machine (3) using a rigid tow bar (2) to
prevent unintentional free-wheeling of
the mower.
NOTICE The free-wheeling mechanism can be accessed at the front of the machine on the left-hand side
between the mower unit and the front wheel. Nothing has to be disassembled to access the mechanism.
Operating 44
