1. Place the wheels in the straight-ahead
position by turning the steering wheel.
2. Rotate the hand wheel (1) clockwise until
it is tightened.
3. Push the hand knob (2) downwards for
approx. 10 times.
CAUTION! Stop pushing when you feel strong resistance: a strong force damages the front wheel motors.
NOTICE The machine can now be towed. Remember that the machine now steers heavily, has a maximum
speed of 2 km/h and a maximum distance of 1000 m.
Turning off the free-wheeling mechanism
Rotate the hand wheel (1) anticlockwise until it can go no further.
The free-wheeling mechanism is now deactivated and the machine has been returned to its original settings.
7.6 After operating the machine
When you are finished operating the machine, please make sure that you:
• park in a safe and secure location.
• turn off the engine and remove the ignition key.
• clean the mowing units (see Cleaning the mowing units on page 58).
• refuel the diesel tank (see Refuelling on page 68).
Operating 45
