RoboSense LIDAR RS-Helios-5515

Questions and Answers

A
Amber GarciaAug 14, 2025
What to do if I can see data in Wireshark but not in RSVIEW RoboSense LIDAR RS-Helios-5515?
- A
  April WheelerAug 14, 2025
  If you can see data in Wireshark but not in RSVIEW, try the following: First, turn off the computer firewall and allow RSVIEW to bypass it. Second, ensure that the IP address of the computer is consistent with the IP address of the LiDAR. Next, verify that the Data Port setting on RSVIEW is correct. Finally, confirm that the RSVIEW installation directory or configuration file storage directory only contains English characters.
A
Ashley RobinsonAug 17, 2025
Why are there frequent data dropouts in my RoboSense Robotics LiDAR?
- K
  Kevin KnoxAug 17, 2025
  If you experience frequent data dropouts with your RoboSense Robotics LiDAR, check the following: First, determine whether there is excessive traffic or collisions on the network. Second, check for other network devices sending excessive broadcast packets, which can slow down the sensor. Third, ensure that the computer or interfaces are fast enough to meet the packet flow requirements. Finally, remove all other network devices and directly connect the sensor to the computer to test for packet loss.
D
Danielle FloresAug 21, 2025
What to do if there is no data output when RoboSense Robotics sensor is connected to a router?
- S
  Suzanne MoonAug 21, 2025
  If your RoboSense Robotics sensor is connected to a router and there is no data output, try turning off the DHCP function of the router or setting the IP address of the sensor to the correct IP address inside the router.
M
Martin KennedyAug 25, 2025
What to do if RoboSense LIDAR RS-Helios-5515 LiDAR rotates but no data output?
- J
  John DuncanAug 25, 2025
  If the LiDAR rotates but there is no data output from your RoboSense Robotics system, check the following: Confirm that the network connection is normal and that the computer network configuration is correct. Use software like Wireshark to check if the packet output is normal. Turn off firewalls and any security software that might be blocking the network. Also, check that the power supply is normal and try restarting the sensor.
R
rodney18Aug 28, 2025
Why is GPS/PTP not synchronizing in RoboSense LIDAR RS-Helios-5515?
- C
  Cody HallAug 28, 2025
  If the GPS/PTP is not synchronizing with your RoboSense Robotics system, ensure the synchronization mode is correctly set on the web page. Verify the GPS baud rate is 9600bps and the serial port is set to 8N1 (8 bits, no parity, 1 stop bit). Check the GPS signal level (3.3V TTL or RS232), ensure the 1PPS pulse is continuous and correctly connected, and confirm the GPRMC message of NMEA is correct. Ensure the GPS and Interface Box share the same ground, the GPS has received a valid message, and the GPS module is outdoors. Finally, check if the PTP Master synchronization protocol complies with the current PTP protocol and if the PTP Master is working correctly.
B
barbarafarmerAug 31, 2025
What to do if RoboSense LIDAR RS-Helios-5515 Robotics LiDAR keeps restarting at startup?
- K
  Kelly GardnerAug 31, 2025
  If the LiDAR keeps restarting at startup, check the input power connection and polarity to ensure they are normal. Make sure the voltage and current of the input power supply meet the requirements (voltage input ≥12V, input current ≥2A). Also, verify that the mounting base of the device is level and that the fixing screws at the bottom of the LiDAR are not too tight.
O
onealaustinSep 3, 2025
How to fix RSVIEW software if it outputs point cloud into a ray in RoboSense Robotics?
- M
  Mitchell MartinezSep 3, 2025
  If the RSVIEW software outputs the point cloud into a ray, and you are using Windows 10, set RSVIEW to run in compatibility mode with Windows 7.
A
Andrew GordonSep 6, 2025
What to do if RoboSense Robotics LiDAR motor does not rotate?
- S
  Stephanie FieldsSep 6, 2025
  If the LiDAR motor does not rotate, check whether the LED indicators on the Interface Box are normal and whether the power input is normal. Also, check if the connection cable between the Interface Box and the LiDAR is loose.
A
Alexander SpearsSep 10, 2025
What to do if the red LED indicator in the Interface Box of RoboSense Robotics is off or blinking?
- M
  mitchellkellySep 12, 2025
  If the red LED indicator in the Interface Box is off or blinking, check whether the input power connection and polarity are normal.

Summary

Safety Notices

Laser Safety

This product meets the following standards for laser products: IEC 60825-1:2014;

Product Appearance and Interface

Aviation Plug and Pin Definition

Details the pins and functions of the aviation plug attached to the LiDAR.

Interface Box

Details the interface box, its LEDs, and port specifications for connectivity.

Unboxing & Installation

Sensor Mounting

Provides details and diagrams for securely mounting the LiDAR sensor.

Sensor Specifications and Features

Sensor Specification Details

Provides detailed technical parameters of the LiDAR sensor, including laser, optics, and output.

Time Synchronization Methods

Explains GPS+PPS and PTP time synchronization methods for accurate timing.

Communication Protocol

MSOP and DIFOP Protocols

Details the Main Data Stream Output Protocol (MSOP) and Device Information Output Protocol (DIFOP).

MSOP Data Stream Protocol

Describes the MSOP protocol, including header, data blocks, and channel data structure.

DIFOP Device Information Protocol

Explains the DIFOP protocol for outputting LiDAR information registers and packet structure.

Troubleshooting Common Issues

Web Interface Operations

Sensor Setting Interface

Details the 'Setting' screen for configuring device IP, port, return mode, rotation speed, and phase.

Information Registers

Fault Diagnosis Register (FALT_DIGS)

Provides fault diagnosis information including temperatures, GPS status, and fault codes.

RoboSense LIDAR RS-Helios-5515 Specifications

General

Model	RS-Helios-5515
Category	Robotics
Laser Wavelength	905 nm
Field of View (Horizontal)	360°
Frame Rate	10 Hz
Operating Voltage	9-36 VDC
Storage Temperature	-40°C to 85°C
Protection Level	IP67
Accuracy	±2 cm
Interface	Ethernet
