Step3. Move to OPT CARD screen
Step4. CARD setup screen
<HW CONF - COM>
COMMUNICATION SET
1: RS232C
2: FIELD BUS
3: LINE SEPARATOR
group #
Select 2: FIELD BUS
Select 1: CARD
Press ESC and then ENTER to save
Select 3: PROFIBUS
<COM-FDBUS >
1: CARD
2: USER I/O
3: PROFIBUS ENDIAN
4: MAP EXTENTION
Input: ■
<FDBUS-CARD>
OPT COM CARD
1: NONE 2: CC-LINK
3: PROFIBUS 4: D-NET
Selected : PROFIBUS■
<FDBUS-CARD>
OPT COM CARD
1: NONE 2: CC-LINK
3: PROFIBUS 4: D-NET
Selected : PROFIBUS■
S
3
 When there is no Profibus B/D, a message “Not Card!” comes up at bottom of T/P
screen and fails to be saved.
