31
Electric connections must be carried out by skilled personnel in compliance with the requirements of the local body energy supplier as
shown in the diagram enclosed to the terminal board of the motor.
Robuschi refuses all responsibility for electric connections not complying with the law in force
Check on the motor plate : Voltage, Absorbed current, Frequency, number of phases.
Wiring diagram accompanies the terminal board of the motor , if the diagram has not been supplied request it from the motor manufacturer.
Use suitable electric cables depending on the nominal current of the electric motor.
Keep the electric cables away from heat sources and/or pointed edges
Verify the hearting system according to the relevant rules
Protect the motor by means of automatic switch set at the rated value of the motors current .
Install a local control panel with an emergency push-button E between supply line and the KRVS near the inlet of the cables
button must be easily reached by the operator
