Urisys - Operator’s Manual V.
CAUTION: To ensure your readings are always accurate, do not set up the Urisys
system in close
proximity to devices that create high-frequency fields, as they may interfere and produce false results.
Such devices include, for instance, walkie-talkies, mobile telephones, microwave ovens and diathermic
equipment.
Instrument connection
Power-on
() Unpack the Urisys system and place it on a stable, level surface. Do not expose the analyzer to direct sunlight or
other source of direct light (for example a spot lamp). For measurements of Combur
Test
®
UX test strips, the test strip
tray with the type mark C on the reverse side is required.
() Connect the AC adapter to the power socket at the rear of the instrument and to a readily accessible AC wall socket.
Insertion of the test strip tray
() Pick up the test strip tray, Type “C”, and with the retaining bar nearest to you pushed down (see Figure ), slide it into
the slot below the function keys, so that the near edge of the test strip tray is flush with the near edge of the analyzer
(see Figure ).
CAUTION: Be careful not to touch the grey reference pad (A).
Contamination of the reference pad may impair the quality of the
results obtained.
ATTENTION: The test strip tray must be replaced months after first
date of use or if the Urisys system cannot be calibrated despite
several attempts (see Section , Calibration).
Figure
Figure
A
Paper Insertion
Figure
Figure
To release the printer paper cover, press the structured area immediately below
the cover (see Figure ). The cover can then be lifted back. Place the paper roll in
the compartment and pull out the first few centimetres of paper to just beyond
the edge of the compartment. The thermosensitive side of the paper (the outer
surface of the paper roll) should be facing downwards (see Figure ). Close the
cover again by pressing until it locks audibly into position.
