E TRAY POSITION ERROR ! Cause: The positioning hole in the test
strip tray (see Figure ) is soiled or still
wet after cleaning; the retaining bar is
open while the test strip tray is
advancing or the retaining bar
mechanism is fouled with urinary
deposit and blocked. (See Section .)
Action: Clean, blow through or dry the
positioning hole (using a lint-free cloth)
to ensure that it is completely patent.
Remove urinary deposits, if there are
any, including those on the underside
of the test strip tray. Insert the test strip
tray again and press the START button.
Ensure that the retaining bar is down
and locked into place while the reading
is taking place. If the error message
appears again, use the spare test strip
tray.
Figure
E WRONG TRAY ! Cause: The test strip tray used is not the one for the programmed test strip type,
or the grey reference pad is missing from the test strip tray, or there is an
instrument error.
Action: Press the START button. The strip type menu is displayed. The strip type
must match the test strip tray type. Use the correct test strip tray, or order a new
one (see Section ). If the error message appears again, the instrument is
defective.
E LIGHT BARRIER ERROR ! Cause: The light barrier used to control the position of the test strip tray is
defective or the test strip tray transport is blocked.
Action: Pull out the test strip tray and return it to the start position. Press the
START button. If the error message appears again, the instrument is defective.
E MOTOR STEP ERROR ! Cause: The stepping of the motor is out of tolerance or the advance of the test
strip tray is blocked. This may be due to
- soiling on or between the cogs
- worn or broken cogs
- defective motor.
Action: Carefully clean the test strip tray. Remove any urinary deposits, including
those on the underside of the test strip tray and the cogs. If the test strip tray is
damaged insert the spare test strip tray. Press the START button. If the error
message appears again, the instrument is defective.
E OPTICS ERROR ! Cause: The reference pad is missing from the test strip tray, or an LED or the
phototransistor is defective.
Action: Attach the reference pad or use the spare test strip tray. Press the START
button. If the error message appears again, the instrument is defective.
CLOSE PRINTER COVER Cause: The printer cover is open.
Action: Close printer cover.
NO PAPER IN PRINTER Cause: No paper has been inserted or roll is finished.
Action: Insert new roll of paper and close printer cover. After elimination of
printer errors the results can be printed from the instrument‘s memory using the
“Print” function.
E INTERFACE ERROR ! Cause: Fault in data transfer to PC or host in bidirectional or ASTM mode.
Action: Check the data cable. Verify that the PC or host is ready to receive data.
Use the “Send” function to transfer data or press “Home” to resume Ready-to-
Measure status.
