16
Need help?
Call 1-800-620-27
90 (U.S. a
nd Canada
)
5
Align the wall
plate (
08
) with the pilot holes,
insert the lag screws (
09
) through
washers (
10
) and into the
holes in the
wall plat
e, then tighten the lag screws only
until they are firm against the wall plate assembly
.
CA
UTION
: Avoid potential injuries or property damage!
DO NO
T over-tighten the lag
screws (
09
).
08
09
10
15
17
