254 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 12 Using microSD Cards
Use the Recipe Feature
Configure Recipe
1. In the Connected Components Workbench software, go to the Properties pane to
configure Recipe.
2. Select Recipe. Click Add Recipe to add a recipe. Note that each recipe will be stored in
separate files. You can add up to 10 recipes per configuration.
3. Click Add Variable to add variables to the recipe. You can add up to 128 variables to
each recipe.
For this quickstart sample project, add the following variables that you have previously
created to RCP 1:
Create Recipe Ladder Program
Configure Recipe
Build and Download
Execute RCP Function Block
Upload Recipe Files
Local Variables
Variable Name Data Type
data_bool BOOL
data_int8 INT
