256 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 12 Using microSD Cards
5. On the Block Selector window that appears, type RCP to filter the Recipe function block
from the list of available function blocks. Click OK.
6. From the Toolbox, double-click rung to add another rung.
7. Add a Direct Contact and RCP function block to this second rung by following steps 3…5.
8. Create the following local variables for your program, in addition to the ones that you
have already created for data log.
Local Variables
Variable Name Data Type
recipe_file STRING
recipe_file2 STRING
cfg_id2 USINT
read BOOL
write BOOL
