16 Publication 2711C-QS001F-EN-P - November 2010
Chapter 1 Review Sample Application
Follow These Steps
Review the sample application.
Purpose of Application
The sample application contains screens and objects to control and monitor the status of a motor. The
PanelView Component terminal reads and writes data to a MicroLogix controller using:
• DF1 point-to-point communication or
• Ethernet communication.
The sample application uses a MicroLogix 1100 controller but you can substitute another MicroLogix model.
Each chapter provides procedures for creating the sample application on a PanelView Component C600
color, touch-screen terminal.
If you want to create this application on another PanelView Component terminal, consider that:
• touch input is automatically enabled for touch-screen terminals.
• function keys must be assigned to objects on keypad terminals.
• text sizes will vary for different terminal sizes.
• color palette on monochrome terminals, shows only two colors, black and white.
The sample application and ladder logic required to run the application on a MicroLogix 1100 controller are
stored on the CD that ships with your terminal under the names:
• QuickStart_T6C.cha - sample application.
• QuickStart.rss - required ladder logic.
page 18
page 19
page 16
Purpose of
Application
Motor Status
Screen
Motor Speed
Screen
page 17
Alarm Banner
page 20
Application
Tags
To Next Page
