Rockwell Automation 9300-ENA User Manual

Ethernet Network Appliance (with Network Address Translation) 11
Publication
9300-IN001A-EN-P - December 2012
Wire the Module
Read this section for information about external power supply wiring.
Provide low voltage DC power to the module by using the screw terminals
contained in the power connector.
32317-M
GND
DC- DC+
Bottom View
Side View
SD Card Slot
Power
Connector
Screw Terminals
Power
receptacle

Rockwell Automation 9300-ENA Specifications

General

Brand	Rockwell Automation
Model	9300-ENA
Category	Network Hardware
Language	English
