Ethernet Network Appliance (with Network Address Translation) 19
Publication
9300-IN001A-EN-P - December 2012
2. Locate the SD card slot on the bottom of the unit.
3. Insert the SD card until it latches.
4. To remove, press and release the SD card to eject it.
Specifications
Technical Specifications
Attribute 9300-ENA
Power requirements 12…48V DC
Class 2/SELV
250 mA @ 24V D
Power dissipation, max 5.8 W @ 60 °C (140 °F)
Thermal dissipation 24.6 BTU/hr @ 60 °C (140 °F) max
Network ports 3 RJ-45 10/100 full/half duplex ports
Protocols TCP/IP, EtherNet/IP, Http, DHCP, Bootp, FTP
Indicators 6 port indicators,
6 status indicators
EtherNet/IP features Link status, connections active
Module features DHCP client, Bootp client
Voltage variation IEC 61000-4-29:
10 ms interruption on DC supply ports
Enclosure type rating Meets IP20
Inrush current, max 2.2 A
