20 Ethernet Network Appliance (with Network Address Translation)
Publication
9300-IN001A-EN-P - December 2012
Isolation voltage
50V (continuous), Basic Insulation Type
No isolation between individual Ethernet ports
Routine tested at 707V AC for 1 s, DC power ports to
ground and DC power ports to Ethernet ports
Wire size Ethernet connections:
RJ45 connector according to IEC 60603-7, 2 or 4 pair
Category 5e min cable according to TIA 568-B.1 or
Category 5 cable according to ISO/IEC 24702
DC Power connections:
0.33... 3.3 mm
2
(22...12 AWG) solid or stranded copper wire
rated at 75 °C (167 °F) or greater, 1.2 mm (3/64 in.)
insulation max
Functional Ground connection:
3.3 mm
2
(12 AWG) solid or stranded copper wire rated at
75 °C (167 °F) or greater
Torque DC power and functional ground: 1.36 N•m (12 lb•in)
Wiring category
(1)
(2)
2 - on DC power ports
2 - on Ethernet ports
North American temp code T4
IEC temp code T3
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial
Automation Wiring and Grounding Guidelines, publication 1770-4.1
.
(2)
Use this Conductor Category information for planning conductor routing as described in the
appropriate system level installation manual.
Technical Specifications
Attribute 9300-ENA
